Description
Specification :
– Generator input – three phase generator – 15 – 95 VAC
– External – ground power – 15 – 80 VDC. Minimum voltage is dependent at
voltage on the main output. Minimal voltage about 5 VDC more then main
output voltage.
– Backup battery input – voltage according to client. Battery voltage must be
lower than main output voltage (max. battery voltage = main output voltage –
0,2VDC )
– Battery charging – charging voltage and current set by clients` battery,
(possibility trimable voltage output)
– Switch – electronic switch controled by external input :
– switch ON – floating
– switch OFF – 3 – 30 VDC ( according to client)
– Max. total wattage – 600W ( more power after consultation)
– Main Output – 3,3 to 42 VDC (60 VDC), max. 20A (25A-consultation) or 500W
– output ripple max. 100mV
– current limit according to client
– possibility trimable by client, for example 3-10VDC, 10-20VDC, 20-30VDC)
– possibility stop main DC converter by external input:
– converter ON – floating
– converter OFF – 3 – 15V ( according to client)
– Secondary Output – 3,3 to 15 VDC, max. 5A or 50W, output ripple max. 100mV
– Operating temperature – -40°C to 80°C
– Connection – all by wires – the lightest solution
