Beschreibung
Instruction:
Connect the charger to the power supply. The IMARS III LOGO will display for about 2 seconds before entering Charger mode. The top-level menu is divided into 3 functions. By pressing +/- buttons; the user may select between charge mode; battery check mode; and system setting mode.
IMARS III PRO pass the FCC; CE and RoHS certifications; making your RC charging more safety. Lightweight design allows you to quickly charge the battery anywhere; anytime.
Features:
1. Single Channel AC Balance Charger
2. Small & Lightweight Portable Design
3. Smart balance charging
4. Capable of 10 amp charge rates; worldwide 100V-240V voltage versatility; with 100 Watts of power
5. Built-in PFC circuit
6. Temperature compensation function
7. Controlled heat dissipation system
8. Quiet inner fan
Specifications:
– Maximum charging voltage: 26.4V
– Maximum charging power: 100W
– Charge current: 0.1~10A
– Discharge current: 0.1~1.5A
– Cell Balancing: 2~6s
– USB output: 5V/2.4A
– Dimensions: 146x87x40 mm
– Product Net Weight: 0.4kg
– Display type: Backlight 2×16 LCD
– Supported battery chemistries: LiPo/LiFe/LiHv (1-6S)?NiMH charge (3-18S)?NiMH discharge (1-10S)
– Accessories included: AC Input Cable / Balance adapter board / XT60-T plug adapter / XT60-EC3 adapter/XT60-EC5 adapter
Our services
1. Your orders will be dispatched via UPS from Germany directly.
2. Fast shipping and excellent local after-sale service guaranteed in Europe.
3. Service-priority in online shop; like the long warranty period and the lower price. We provide 1 year warranty; there would be a special discount provided for orders been over 1 year.
4. Energy Density: Special adapted to each UAV type and RC car/boat/heli type. Very High according to capacity/weight. In fact; we are specialists in High Power Lipo Batteries. It is our unique technology; the highest power of our battery is 100C. Another technology is our batteries are able to be stably discharged simultaneously.
5. Low IR: Provides stable voltage until the end of your mission.
6. Safety: Gens Ace and its’ partners fulfill the ISO9001; ISO14001 standards.
Caution:
Don’t put it besides the high-temperature condition.
Don’t throw it into the fire.
Don’t throw it into the water.
If you are in the USA; you can check here on USA warehouse.
